462 Step 6: Select Your

Turnbuckles better best 1 StableLoad NO-DRILL APPLICATION equires factory predrilled 1/2" diameter holes in lower overload spring. The no-drill Quick
Disconnect StableLoad is designed for vehicles that have a lower overload leaf suspension with a hole near each end of the lower
GOOD
SECTION 14 Basic SpringLoad Kit SpringLoad XL Original FastGun 730973 2 spring pack. In most cases, there will be a plastic disc covering the hole in question.
overload spring. The lower overload will, for the most part be shorter, thicker and will generally have separation from the rest of the
Quick Disconnect Stableload (WITH DRILL KIT) will fit any passenger or commercial vehicle, van, SUV, truck, RV etc. with rear leaf
springs and lower overload spring. The lower overload leaf can be identified by being on the very bottom of the spring pack, being
Stainless Steel Polished
730965
thicker than the rest of the leaf springs in the spring pack and generally speaking having a gap between the lower overload leaf spring
730967
MFG# S9000
MFG# S9526 $499.73
and the upper leaf spring pack. Drilling four 7/16” holes required. Specially treated drill bits and detailed drilling instructions are
MFG# S9050A
$144.29
included. Average drill time is 30-40 minutes for complete installation. Ask about the new StableLoad Drill Tool that reduces installation
$261.43
Powder Coated Grey
730971
time to just 37 seconds per leafspring. Many factory overload springs come predrilled with 1/2" holes. Therefore drilling holes in the
MFG# S9522 $484.48
operation. The drilled springs (when drilled in accordance with the Torklift International drilling specifications) and the integrity of the
730976
Powder Coated Black
springs once drilled are covered under the Lifetime Torklift International Warranty. Some overload springs may have adhesive padding
MFG# S9529 $484.48 overload springs in the same factory locations found on vehicles with predrilled holes will have no affect on your springs integrity or
on top of the overload spring. Use a screwdriver or equivalent to remove the padding. This will ensure proper rotation and ease of use.
CARRIERS & HAULERS
Bright White 730977 StableLoad Drill Tool available through manufacturer. Call for details.
MFG# S9530 $495.47 3 The A7200, A7202, and A7210 is a NO-DRILL APPLICATION and must have factory installed upper overload. Will not work in
conjunction with Supersprings. Due to factory overload engagement design, some applications have progressive engagement, where
rear springs will contact first. Drilling of rubber pad on some older Dodge applications may be required. Depending on the vehicle
model, suspension package, and condition, actual distance between the StableLoad and vehicle frame overload contact bracket may
vary. In some rare instances, when the vehicle is not carrying a load, the StableLoad may come into contact on occasion due to rough
road conditions and other anomalies. #A7201 Spacer kit is available for vehicles that need additional spacing for the StableLoad to
contact the overload spring.
4 On Quick Disconnect StableLoad due to wear and tear after time, some vehicles leaf springs may have minimal clearance with the
lower overload for StableLoad engagement / disengagement when the vehicle is unloaded. In order for the StableLoad to engage and
disengage with minimal effort, a minimum gap of 1/8" is required between the lower overload and the spring pack.
5 There is no fit for the 3500/E350 Cab and Chassis.
6 If your Nissan Titan has an Axle wrap bracket located at the rear of the lower leaf spring, Lower StableLoads may only be installed on
the forward end of the driver and passenger leaf springs.
7 Due to clearance issues, the StableLoad will only work on the rear of the spring.
8 Will not work with factory installed airbags on 3500 trucks. This is due to the lack of both upper and lower overload springs.
Tie Down Footnotes
2 Drilling may be required into the Spring Hanger Bracket which is welded to the frame.
3 Drilling may be required for installation.
4 May require modifications to the running board/bed access step brackets to install Tie Downs.
5 Additional labor required for installation of Tie Downs.
6 Front Tie Down is available in adjustable Tie Down style only.
9 The Toyota HD Tow Package attaches to the side and bottom of the vehicles frame. The Standard Toyota Tow Package attaches to the
bottom of the vehicles frame only.
10 To determine the correct fit: 1500 & 2500 model/classic body style vehicle owners must measure the vehicle frame height at the back
of the truck next to the spare tire. If the frame is 5.5" tall it requires the LD application. If the frame is 8" tall it requires the HD applica-
tion.
11 Will work with aftermarket hitches that do not have side plates that attach to the bottom of the frame.
12 Tie Down requires 4”x4” footprint on the side plate of the aftermarket hitch in order to install. Drilling four holes per side is required for
install.
14 Dually applications may require the use of (#A7004 Dually Adapter Kit). Measure from front of camper slide in point to the rear anchor
point. If total is 90" or less, use Dually Adapter Kit.
15 Requires a factory installed hitch receiver with an open ended cross tube.
SPECIAL ORDER 18 height.
Designed to work with the factory installed running board that extends past the cab and onto the bed. Tie Down is not adjustable in
16
Toyota Tacoma models with a 5' bed & running boards under the cab will need to remove the running boards to install this tie down.
20
Will not work with aftermarket Mopar rear mounted kick out steps that are mounted under the bumper.
22
This Tie Down mounts to the cab mount. You will need to remove the running boards to install this Tie Down.
23
25 If you are using an older one piece SuperHitch, please call 800.246.8132 for rear Tie Down applications.
There were no factory options for a factory hitch for this vehicle. Hitches that were installed on this truck were dealer installed aftermar-
ket hitch options. Select aftermarket hitch on app guide main page step 3.
PRICES SUBJECT TO CHANGE WITHOUT NOTICE
27 Will not work with HiddenPower due to Tie Down design.
28 Works with NO running boards, even the ones that are just under the cab. If you have running boards under your cab, you will need
front tie down D2127/D2127A.
29 Works with any factory running boards/bed access steps, including the ones that are only under the cab.
30 Due to compressor location this Tie Down can't be installed with factory airbags.
31 If your truck is equipped with factory airbags and no running boards, use D2126/D2126A. If your truck is equipped with factory airbags
and running boards of any length, use D2127/D2127A.
For footnotes, see last page of app guide
32 This Tie Down will not work with factory under bed flip out steps.
33 Works with OEM cab length or wheel-to-wheel running boards
Not all vehicle fits listed. Contact us if your application is not listed.
