StableLoad Footnotes
1 StableLoad NO-DRILL APPLICATION equires factory predrilled 1/2" diameter holes in lower overload spring. The no-drill Quick
Disconnect StableLoad is designed for vehicles that have a lower overload leaf suspension with a hole near each end of the lower
overload spring. The lower overload will, for the most part be shorter, thicker and will generally have separation from the rest of the
spring pack. In most cases, there will be a plastic disc covering the hole in question.
2 Quick Disconnect Stableload (WITH DRILL KIT) will fit any passenger or commercial vehicle, van, SUV, truck, RV etc. with rear leaf
springs and lower overload spring. The lower overload leaf can be identified by being on the very bottom of the spring pack, being
thicker than the rest of the leaf springs in the spring pack and generally speaking having a gap between the lower overload leaf spring SECTION 14
and the upper leaf spring pack. Drilling four 7/16” holes required. Specially treated drill bits and detailed drilling instructions are
included. Average drill time is 30-40 minutes for complete installation. Ask about the new StableLoad Drill Tool that reduces installation
time to just 37 seconds per leafspring. Many factory overload springs come predrilled with 1/2" holes. Therefore drilling holes in the
overload springs in the same factory locations found on vehicles with predrilled holes will have no affect on your springs integrity or
operation. The drilled springs (when drilled in accordance with the Torklift International drilling specifications) and the integrity of the
springs once drilled are covered under the Lifetime Torklift International Warranty. Some overload springs may have adhesive padding
on top of the overload spring. Use a screwdriver or equivalent to remove the padding. This will ensure proper rotation and ease of use.
StableLoad Drill Tool available through manufacturer. Call for details.
3 The A7200, A7202, and A7210 is a NO-DRILL APPLICATION and must have factory installed upper overload. Will not work in
conjunction with Supersprings. Due to factory overload engagement design, some applications have progressive engagement, where
rear springs will contact first. Drilling of rubber pad on some older Dodge applications may be required. Depending on the vehicle
model, suspension package, and condition, actual distance between the StableLoad and vehicle frame overload contact bracket may
vary. In some rare instances, when the vehicle is not carrying a load, the StableLoad may come into contact on occasion due to rough
road conditions and other anomalies. #A7201 Spacer kit is available for vehicles that need additional spacing for the StableLoad to
contact the overload spring.
4 On Quick Disconnect StableLoad due to wear and tear after time, some vehicles leaf springs may have minimal clearance with the
lower overload for StableLoad engagement / disengagement when the vehicle is unloaded. In order for the StableLoad to engage and
disengage with minimal effort, a minimum gap of 1/8" is required between the lower overload and the spring pack.
5 There is no fit for the 3500/E350 Cab and Chassis.
6 If your Nissan Titan has an Axle wrap bracket located at the rear of the lower leaf spring, Lower StableLoads may only be installed on
the forward end of the driver and passenger leaf springs.
7 Due to clearance issues, the StableLoad will only work on the rear of the spring. CARRIERS & HAULERS
8 Will not work with factory installed airbags on 3500 trucks. This is due to the lack of both upper and lower overload springs.

HiddenPower Footnotes
1 Battery box is not included.
2 Requires drilling into the vehicle frame. This is a universal fit application.
SuperHitch Footnotes
1A Rated at 1,500 lbs tongue weight distributing and 15,000 lbs pulling capacity weight distributing.
1B Rated at 2,000 lbs tongue weight distributing and 20,000 lbs pulling capacity weight distributing.
1C Rated at 3,000 lbs tongue weight distributing and 30,000 lbs pulling capacity weight distributing.
1 Spare tire hanger and tailpipe modification may be necessary.
2 May require modification to spare tire hanger.
3 Will only work with factory welded on receiver hitch .
4 2007 fits only classic body style.
5 Trucks with 34½" cab and chassis frame use F1003; trucks with a 37½" regular pickup frame use F1002.
6 Works with vehicles that have factory rims and tires 18" and smaller.
7 T1300H cannot be installed on trucks with suspension airbags. Torklift recommends StableLoads as an alternative.
1H It is not compatible with factory hitch rated to 11,500 lbs.
2H Comes with a single receiver that combines with factory hitch.
3H In some rare cases, due to the manufacturing tolerances of the factory Toyota hitch, there will not be enough clearance for the T1300H
SuperHitch Hero.
To provide the clearance needed, it may be necessary to lightly grind the lower portion of the factory receiver strap. PRICES SUBJECT TO CHANGE WITHOUT NOTICE
